Littelfuse TDUIL3002A is a compact and reliable solid-state relay designed for various applications. With a load rating of 1A steady state and 10A inrush at 60°C, it ensures high performance. The termination type is 0.25 in. male quick connect terminals. It operates at an input AC line frequency of 50/60 Hz with a tolerance of ±20%. With a humidity resistance of 95% relative non-condensing, it is suitable for different environments. The relay offers repeat accuracy of ±0.5% or 20ms and insulation resistance of ≥100. It has a low power consumption of ≤2VA and a quick reset time of ≤150ms. The dielectric breakdown is ≥2000V between terminals and the mounting surface, ensuring safety. The output voltage drop is approximately 2.5V at 1A, and the open-state leakage current is around 5A at 240V AC. Setting accuracy is ≤±2% or 50ms. Trust the TDUIL3002A for reliable and hassle-free switching operations.
