Littelfuse KSDB134P is a compact, encapsulated DC solid state relay with a 1A steady state output load rating and 10A inrush at 60°C. It features 0.25 in. male quick connect terminals for easy installation. With a wide input tolerance of ±20% and humidity resistance of 95%, it offers reliable performance in various environments. The relay promises repeat accuracy of ±0.5% or 20ms, whichever is greater, and insulation resistance of ≥100. It has a low power consumption of ≤2W and a time delay tolerance of ±5%. The reset time is ≤150ms. Other notable features include a dielectric breakdown of ≥2000V terminals to mounting surface, an output voltage drop of ≅1V @ 1A, an open-state leakage current of ≅1A, and an initiate time of ≤20ms. Compatible with positive switching and offering reverse polarity protection, this solid state relay is a reliable choice for a wide range of DC applications.
