Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 897028
Omega DPF66-RS422 RT/BTCH CNTRLR RS422
Normally In Stock
Omega DPF66-RS422 RT/BTCH CNTRLR RS422
Condition: New
Usually ships Same Day or Next Day$1029.72
Sale Price
$858.10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Omega DPF66-RS422 RT/BTCH CNTRLR RS422
Specifications
Component
Meter
Manufacturer
Omega Engineering
Features
The DPF60 is a combination microprocessor-based digital rate indicator and integrating totalizer
It accepts inputs of 4 to 20 mA, 0 to 20 mA, 0 to 5V, or 1 to 5V and can be scaled for engineering units directly from the nema 4X (IP66) rated front panel without tweaking internal potentiometers
The dual standard 5 A (@ 250 Vac) relays can be assigned to the ratemeter, or to the totalizer, or one relay to each for batch control and rate alarm
The display features a floating decimal point that moves left or right depending on how many “significant figures” the user has selected
In the totalizer mode, 6-digits can be displayed
The unit is fully scalable from 0 to 59,999, which indicates the flow rate represented at 20 mA
A peak and valley feature allows the user to call up the recent high and low readings
A square-root extracting input is optional on all units for use with differential pressure flowmeters, such as orifice plates and pitot tubes
With the DPF66, the user can toggle between rate of flow and total flow (6-digits) from the front panel
The rate display is selectable for units per second, minute, or hour, and the totalizer integrates in the same engineering units
The DPF65 displays just total flow, while the DPF64 only displays rate of flow.
Downloads
No current downloads for this product. Please call us at 888-532-2706 for more information.
