Code: 806229
Omega DP3600-2-3 Programmable Process Monitor
Normally In Stock
Omega DP3600-2-3 Programmable Process Monitor
Condition: New
Usually ships Same Day or Next Day$810.68
Sale Price
$675.57
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Programmable Process Monitor, 1/8 DIN, 6 Digit, 7-Segment LED Display, DC Supply, 4 mA to 20 mA I/P, 9 Vdc to 15 Vdc Power & 4 SPDT Process/2 Open-Collector Timer Alarm O/P, 3600 Series, Each
Specifications
Manufacturer
Omega Engineering
Component
Programmable Process Monitor
Features
Front Keypad Scaling to Display in Engineering Units
Tracks Min/Max Readings
Three Programmable Alphas for Engineering Units e.g. “psi”
Two Process, One Rate and One Deviation Alarm (optional)
A/D ConversionDual slope, integrating
Accuracy± 0.05 %
Conversion Rate20,000 counts
Cutout Dimensions45 x 92 mm
Deadband0 to 100%
Display Type6 Digit Single LED
Enclosure RatingsIP65, NEMA Type 4
FeaturesRemote hold and tare
Form factor1/8 DIN Rail
Front Bezel112 W x 57 H x 11 D mm
Height45 mm
Length234 mm
Number of Inputs1
Rate Time Base1 to 65,000 sec
Sampling Rate1 Hz (1 update/second)
Scaling1 to 30,000
Sensor/Transmitter Power5 Vdc @ 50 mA
Supply Power Note120 Vac standard
220 Vac, 50 Hz
8 to 12 Vdc @ 900 mA optional
Supply Power TypeAC
Width91 mm
