Omega DMD4059 STRAIN GAGE TO DC TRANSMITTER
Normally In Stock
Code: 790190
Omega DMD4059 STRAIN GAGE TO DC TRANSMITTER
Condition: New
Usually ships Same Day or Next Day$868.73
Sale Price
$723.94
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
DIN Rail Signal Conditioner, AC Supply, 0 mV to 400 mV DC I/P, Bridge, Strain I/P & Process O/P Class, DMD4059 Series, Each
Specifications
Conditioner Number Input Signals
1 Input Signal
Component
Signal Conditioner
Conditioner Output Signal Type
Current
Conditioner Output Signal Type
Voltage
Conditioner Input Signal Type
Voltage
Manufacturer
Omega Engineering
Conditioner Output Signal Range
0-25 Ma
Conditioner Supply Voltage
80-265 Vac
Conditioner Supply Voltage
85-300 Vdc
Features
Standard DIN Rail Mounting
Non-Interactive Zero and Span
Fast Setup - Over 100 I/O Ranges
Removable Connectors
Adjustments±5% Via Multi-Turn Potentiometer
CMRR100 db min
Electrical ConnectionScrew Terminal
Electrical Output0 to 25 mA
Enclosure RatingsIP40
Height117 mm
Isolation1200 Vrms minimum, 3-way isolation, power to input, power to output and input to output
Length122 mm
MountingDIN Rail 35 mm Standard
OffsetZero Offset (Tare): ± 100% of span in 15 % increments
Operating Temperature, Max60 °C
Operating Temperature, Min-10 °C
Output RippleBetter than ±0.1% of span, <10 mV rms ripple and noise
Output ValueProcess
Power Consumption2 to 5 W
Resistance AccuracyBetter than ±0.01% per 1 Ω change in leadwire resistance
Stability±0.01% per °C, Thermal: Better than ±0.02% of span per °C
Supply Power TypeAC/DC
Temperature Stability±0.01% per/°C
Better than ±0.02% of span per °C
Weight159 g
Width22.5 mm
Wire Gauge14 AWG
