Dwyer 605-6 Magnehelic® Differential Pressure Indicating Transmitter
Normally In Stock
Code: 570323
Dwyer 605-6 - Differential pressure indicating transmitter, range 0-6.0" w.c., max. pressure 2 psi (13.79 kPa), ±0.5% electrical accuracy, ±2% mechanical accuracy.
Condition: New
Usually ships Same Day or Next Day$565.99
Sale Price
$471.66
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer 605-6 is a Magnehelic® Differential Pressure Indicating Transmitter with a temperature range of 20 to 120°F (-6.67 to 48.9°C). It operates on a 10 to 35 VDC power requirement and has a 4 to 20 mA output signal. The transmitter is suitable for air and non-combustible, compatible gases. It features protected potentiometers for zero and span adjustments and has a diaphragm in the vertical mounting orientation. With a 4" dial face and dimensions of 5" (127 mm) OD x 2-11/16" (68.3 mm), this transmitter offers stability of ±1% FS/yr.
Specifications
Component
Differential Pressure Transmitter
(Instrument-Sensor) Application
Air And Non-Combustible Compatible Gases
(Instrument-Sensor) Supply Voltage
10-35 VDC
(Instrument-Sensor) Type
Magnehelic® Differential
(Instrument-Sensor) Temperature Range
20 - 120°F/-6.67 - 48.9°C
Manufacturer
Dwyer Instruments
Features
Easy to read gage permits viewing from far away
Patented design provides quick response to pressure changes means no delay in signaling and alerting to critical situations
Durable and rugged housing and high-quality components combined provides longservice life and minimized down-time
Optional stainless steel bezel is the same installation diameter as Magnehelic® gage and simplifies field upgrade to 605 indicating transmitter
