Littelfuse 35060026 is a versatile product with a Pilot Duty load rating of 480 VA at 240 Volts and a General Purpose load rating of 1-10 A or 1 hp at 240 Volts. It has Torque termination of 7 in-lbs and can accommodate wire sizes of 12-18 AWG. The input AC line frequency is 50/60 Hz and an increase to 50 Hz will automatically increase all delay timers by 20%. It has a 90% undervoltage trip voltage and trip delay ranges of 4s for under voltage and 2s for unbalance/phase faults. The maximum input power is 5. It has a restart delay range of 2-300s which is manually adjustable. The undervoltage reset voltage is 93% and the voltage unbalance trip point is 6%. The voltage unbalance reset is 4.50%. It has a trip point accuracy of ±1%.
