Littelfuse 350600 is a versatile relay with a pilot duty rating of 470 VA at 600 volts and a general-purpose rating of 10 A. It has a torque termination of 7 in-lbs and accommodates wire sizes from 12 to 18 AWG. The input AC line frequency can be either 50 or 60 Hz, with the former increasing all delay timers by 20%. It has an undervoltage trip voltage of 90%, a trip delay range of 4 s for undervoltage and 2 s for unbalance/phase faults. The maximum input power is 5 VA and it has a restart delay range of 2 s after a fault or a complete power loss. The undervoltage reset voltage is 93% and the voltage unbalance trip and reset points are 6% and 4.50% respectively, with a trip point accuracy of ±1%.
