Littelfuse 35020026 Voltage Monitoring - 190-240 Volt, Double Throw, Double Pole
Normally In Stock
Code: 565695
Littelfuse 35020026 - 350 Series – Three-Phase Voltage Monitor Relay Series - 190-240 Volt - #8 screws - Pilot Duty: 480 VA @ 240 VAC; General Purpose: 1 - 10 A and Pilot Duty: 480 VA and 240 VAC; General Purpose: 1 hp @ 240 VAC
Condition: New
Usually ships Same Day or Next Day$355.84
Sale Price
$296.53
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Littelfuse 35020026 is a versatile product designed for various load ratings. It supports pilot duty with a capacity of 480VA at 240 Volts and general purpose applications with a range of 1-10A or 1 hp at 240 Volts. The torque termination ensures secure connections with wire sizes between 12-18 AWG. It operates at both 50/60Hz frequencies, with built-in delay timers. The undervoltage trip voltage is set at 90%, while trip delays range from 4s for under voltage to 2s for unbalance/phase faults. It has a maximum input power of 5 and adjustable restart delay from 2-300s. The undervoltage reset voltage is set at 93%, with a voltage unbalance trip point of 6% and reset of 4.50%. Trip point accuracy is within ±1%.
Specifications
Relay Throws
Double Throw
Relay Poles
Double Pole
Component
Voltage Monitoring Relay
Manufacturer
Littelfuse
Relay Mounting
Screw
Coil Voltage Rating
190-240 Volt
