ACI 130842 A/TT1K-O-4-4X-POTTED Transmitter,1K Ohm Outside Air RTD
Normally In Stock
Code: 176030
ACI 130842 Transmitter w/ 1,000 Ohm RTD, Outside Air, NEMA 4X Enclosure, 4-20mA Output, Potted Board
Condition: New
Backordered with 10-12 week lead time$150.66
Sale Price
$125.55
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
The ACI Transmitter Outside Air Series features a two-wire, 4 to 20 mA loop powered output with optional 3-Wire voltage output signals available. These units are designed to be mounted out of direct sunlight on the North side of a building or under an eave or intake hood. The Ruggedized epoxy coated transmitters “-POT” option should be used in extreme environments or in applications where you are looking for improved accuracy and reduced thermal drift due to the thermally conductive epoxy and more consistent board temperatures. Zero and Span adjustments are available for recalibration in the field when using NIST Certified equipment. All units include a Weather Proof or NEMA/IP rated enclosure and 1/2” knockouts or ½” NPT threaded hubs for use during installation. We recommend the use of 18 to 22 AWG shielded cable for all temperature transmitter installations to protect against the introduction of noise onto the signal lines. ACI does offer recalibration services for any transmitters sent back to us for a nominal fee. Applications: Outside Air Temperature Sensing, Economizer Control, Cold Storage Facilities or Warehouses, High Moisture Environments
Specifications
Manufacturer
ACI
Component
RTD
(Instrument-Sensor) Mounting
Outside Air
(Instrument-Sensor) Type
Transmitter-1K Ohm
