Code: 818561
Omega DIN-115 DIN Rail Digital Transmitter
Normally In Stock
Omega DIN-115 DIN Rail Digital Transmitter
Condition: New
Usually ships Same Day or Next Day$414.78
Sale Price
$345.65
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
DIN Rail Digital Transmitter, +100 V I/P, RS485 O/P, DIN-100 Series, Each
Specifications
Manufacturer
Omega Engineering
Component
Digital Transmitter
Features
Complete Sensor to RS-485 Interface
500V RMS Analog Input Isolation
15-Bit Measurement Resolution
Continuous Self-Calibration
Accuracy± 0.05 %
Additional Features 1Address: User Selectable Channel address
Multi-Drop Modules: Up to 247 multi-drop modules per host serial port
ApprovalsCE
Baud Rate300 to 38,400
CalibrationAutozero and autocalibration
no adjustment pots
CMRR100 dB at 50/60Hz, 500V RMS max CMV, input to output at 60Hz
Conversion Rate8 Conversions per Second
Data FormatNRZ Asynchronous
Data InterfaceModbus RTU, ASCII, RS485
Electrical ConnectionScrew Terminal
Excitation Voltage10 Vdc
FilterDigital Filtering: Small and large signal with user selectable time
constants from 0 to 16 seconds
Height83.9 mm
Leakage Current< 2 μA
Length86.5 mm
MaterialsABS
MemoryNon Volatile Memory Eliminates pots and Switches
Microcomputer8-bit CMOS
digital scaling, linearization and calibration
Number of Inputs1
OffsetOffset Control: Full input range
Operating Temperature, Max70 °C
Operating Temperature, Min-25 °C
Output SignalRS485
Output ValueProcess
ParityOdd, Even, None
Relative Humidity0 to 95% RH (non-condensing)
Serial NumberInput Burnout Protection: To 250 Vac normal mode
SoftwareWindows PC Software
Storage Temperature, Max85 °C
Storage Temperature, Min-25 °C
Supply Power NoteRegulated +5 Vdc, 0.75 W max (DIN-150, 2.0 W max)
protected against power supply reversals
Supply Power TypeDC
Supply Voltage± 5 Vdc
Temperature CoefficientSpan Temperature Coefficient: +50 ppm/°C max
Width25.4 mm
