2-Channel Input

Simultaneous Display

AC Line-Voltage or DC Powered

Display and/or Control: µS, mS, PPM or PPB (TDS), kohms, Mohms, % Rejection, Difference, Ratio, °C or °F

Accuracy± 2 %

Additional Features 1Dual Channel

NEMA 4X (IP65) front and back with optional NEMA 4X (IP65) rear cover kit

Conductivity Measurement0.055 to 400,000 µS/cm

Display Type2 x 16 Alphanumeric LCD

Display Type NoteAlphanumeric 2 x 16 LCD Contrast: User selected, 5 levels Update rate: 1.5 seconds

Enclosure RatingsIP65, NEMA Type 4X

Frequency50/60 Hz

MaterialsPBT, Polycarbonate

Number of RelaysNone

Operating Range NoteResistivity: 10 kΩ/cm to 18.26 MΩ/cm (0.055 to 100 μS/cm)

TDS: 0.001 to 999999 ppm or ppb (display limit)

Operating Temperature, Max120 °C

Operating Temperature, Min-25 °C

Output DetailCurrent Outputs: (3 each) 4 to 20 mA, isolated, fully adjustable and reversible Max Loop Impedance: 150 Ω @ 12V, 450 Ω @ 18V, 750 Ω @ 24V Update Rate: Approx. 100 mS Accuracy: ±0.03 mA @ 25°C, 24 Vdc Open Collector Outputs: (2 each) Isolated, 50 mA sink or source, 30 Vdc max pull-up voltage Operational Settings: Hi, Lo, USP, Pulse, Off Hysteresis: User adjustable Time Delay: 0 to 6400 seconds Maximum Pulse Rate: 400 pulses/minute

Power Consumption20 VA

Relay Note(up to 4 each) SPDT Relays Maximum Voltage Ratings: 5A @ 30 Vdc or 5A @ 250 Vac Operational Settings: Hi, Lo, USP, Pulse, Off Hysteresis: User adjustable Time Delay: 0 to 6400 seconds Maximum Pulse Rate: 400 pulses/minute

Resistivity Measurement Range10 kΩ/cm to 18.26 MΩ/cm

Temperature Accuracy± 0.5 °C

Weight581 g
