Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Omega D8200 7 CH DIF CURRENT INPT MODULECE
Normally In Stock
Code: 790260
Omega D8200 7 CH DIF CURRENT INPT MODULECE
Condition: New
Usually ships Same Day or Next Day$667.20
Sale Price
$556.00
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
USB Interface Module, Process Current I/P, 25/s Sample Rate, 16 °C, 7 Inputs, ± 20 mA, DC Power, Modbus RTU, D8000 Series, Each
Specifications
Conditioner Output Signal Range
0-20 Ma
Conditioner Output Signal Range
4-20 Ma
Conditioner Input Signal Type
Current
Manufacturer
Omega Engineering
Conditioner Supply Voltage
10-30 Vdc
Component
USB Interface Module
Features
Complete Data Acquisition Systems
Analog and Digital I/O Models Available
USB Interface
Modbus® RTU Protocol
Common Mode VoltageInput to Output at 115 Vrms, 60 Hz: 500 Vrms
Data InterfaceUSB
Data Interface NoteModbus RTU protocol
Configuration Method: Modbus
Digital FilterProgrammable
Electrical ConnectionScrew Terminal
Electrical Output0 to 20 mA, 4 to 20 mA
Height102 mm
Input Voltage NoteAbsolute Maximum Input Voltage: ±10V
Length38 mm
MaterialsABS
MemoryEEPROM
Mounting Note165 mm on center
Operating Temperature, Max70 °C
Operating Temperature, Min-25 °C
Output Settling Time0.1% FS: 1 ms
Relative Humidity0 to 95% RH non-condensing
Storage Temperature, Max85 °C
Storage Temperature, Min-25 °C
Supply Power TypeDC
Supply Voltage10 to 30 Vdc
Width152 mm
