Code: 787576
Omega 5SE01313-9 PRESS TRANS HIGH ACC 0-1K PSIG
Normally In Stock
Omega 5SE01313-9 PRESS TRANS HIGH ACC 0-1K PSIG
Condition: New
Usually ships Same Day or Next Day$2002.56
Sale Price
$1668.80
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Marine Pressure Transducer, Gauge, 0 psi to 1000 psi, ± 0.25 %, 1/4 " NPT Female, Voltage, 0 Vdc to 5 Vdc, MIL-26482-I 10-6P, SS, 5SE Series, Each
Specifications
(Instrument-Sensor) Output Signal Range
0 - 5 V
Manufacturer
Omega Engineering
(Instrument-Sensor) Span
0 To 1000 Psi
(Instrument-Sensor) Connection Type
NPT Female
Component
Marine Pressure Transducer
Features
High 0.25% Accuracy
Rugged Thick Film Design
Proven Performance in Extreme Applications
All Stainless Steel Construction
Accuracy± 0.25 %
Accuracy Class0.1% to 0.25%
Accuracy DetailCombined Effects Non-Linearity, Hysteresis and Repeatability: 0.25% RO (Max.)
Compensated Temperature, Max150 °F
Compensated Temperature, Min-25 °F
Electrical Output0 to 5 V
Electrical Output Note5 VDC ± 0.25% (± 10% Adjustable) Short Circuit Protected
Stability0.4% RO
Stability NoteThermal Zero Stability: 0.4% RO (Max.)
Thermal Sensitivity Stability: 0.3% RO (Max.)
Supply Voltage28 Vdc ± 4 Vdc
Thermal Effect0.0020/°F (0.0036/°C) Max.
Thermal Effect on Zero error, Max0.0015/°F (0.0027%/°C) Max.
Vibration(5-2000 Hz): 0.04% RO/G (Max.)
Zero/Balance Error± 10% Adjustable (Min.)
