Code: 784106
Omega EP211-X15 E/P CONVERTER CE WARNING:
Normally In Stock
Omega EP211-X15 E/P CONVERTER CE
WARNING:
Condition: New
Usually ships Same Day or Next Day$831.01
Sale Price
$692.51
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
General Purpose Electropneumatic Transducer, 1/4 " NPT Female, ± 1.5 % Accuracy, 1 Vdc to 5 Vdc, 3 psi to 15 psi, Conduit Connection, EP211 Series, Each
Specifications
Component
Pressure Regulator
Manufacturer
Omega Engineering
Features
Low Cost
Built-in Volume Booster
Small Size
Field Reversible
Accuracy± 2.5 %
Accuracy DetailIncludes linearity, hysteresis and repeatability
Electrical ConnectionDIN 43560 connector
EMC StandardIEC 61000-4-3
Enclosure RatingsIP65, NEMA Type 4X
Enclosure TypeN/A
Flow Rate Note12 scfm @ 100 psig
20 scfm @ 150 psig
Input Control SignalN/A
MaterialsStainless Steel, Brass, Zinc, Epoxy, Chromated Aluminum, NBR
Media CompatibilityClean Dry Air
MountingDirect wall, panel, DIN rail
Operating Temperature, Max60 °C
Operating Temperature, Min-30 °C
Process Connection Size1/4 in
Process Connection TypeNPT Female
Supply Pressure Sensitivity0.1% of span per psi (±0.02% for zero-based units)
Total Air Consumption6 SCFH
Volumetric Flow Rate, Max12 SCFM
Weight590 g
