Code: 780146
Omega FL-7320ABR 3/4" BRASS WATER 2.0- 20 GPM
Normally In Stock
Omega FL-7320ABR 3/4" BRASS WATER 2.0- 20 GPM
Condition: New
Usually ships Same Day or Next Day$976.96
Sale Price
$814.13
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Variable Area Flow Meter, Economical, In-line, Water, 2 GPM to 20 GPM, 3500 psi, 3/4 " NPT Female, Direct Read, Brass, 302 SS, Polyphenylene Sulfide, Ceramic, FKM, FL-7000A Series, Each
Specifications
Manufacturer
Omega Engineering
(Instrument-Sensor) Medium
Water
Component
Variable Area Flow Meter
Features
± 2% Full Scale Accuracy
1% Full Scale Repeatability
Mounts in Any Position
Good Viscosity Stability
Accuracy± 2 %, ± 5% with transitional flow
Additional Features 1Dual Scale (GPM/LPM)
Height2.48 in
Length7.16 in
Materials, WettedAluminum, Ceramic, FKM, Polypropylene, Stainless Steel
Operating Pressure, Max3500 psi
Process Connection Size3/4 in
Process Connection TypeNPT Female
Process Temperature, Max116 °C
Repeatability± 1%
ScaleDirect Read
Specific Gravity0.876
Valve Includedfalse
Viscosity Note44 to 400 SSU (± 5%)
Viscosity Range44 to 400 SSU (± 5%)
Weight2 lb
Width2.85 in
