Code: 779689
Omega FTB-102 TURBINE FLOWMETER-.75-7.5 CE
Normally In Stock
Omega FTB-102 TURBINE FLOWMETER-.75-7.5 CE
Condition: New
Usually ships Same Day or Next Day$2855.32
Sale Price
$2379.43
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Turbine Flow Meter, Economical Ball-Bearing, Liquid, 0.75 GPM to 7.5 GPM, 1/2 ", NPT Male, ± 0.5 %, Sinusoidal Wave, 304 SS, 17-4 SS, Ceramic, FTB-100 Series, Each
Specifications
(Instrument-Sensor) Medium
Liquids
Manufacturer
Omega Engineering
Component
Turbine Flow Meter
Features
NIST Certificate Included for Water
±1/2% Rdg Accuracy
Non-Metallic Bearing Retainers for Long Life
Replacement Bearings Field Installable Without Loss of Calibration
Accuracy± 0.5 %
CertificationsNIST Traceable Calibration
Electrical OutputSinusoidal Wave
Materials, Wetted17-4 Stainless Steel, 304 Stainless Steel, Ceramic
Media CompatibilityLiquids
Output DetailMinimum Output Amplitude: 30 mV Peak-to-Peak unscaled dc_pulse
Output SignalDC Pulse
Overload, Max150% of maximum range
Process Connection TypeNPT Male
Repeatability±0.1%
Required Straight Pipe, Min10 Pipe Diameters Upstream, 5 Downstream
