Code: 779491
Omega FP6511 HOT TAP INSERTION PDLWHL SNSR
Normally In Stock
Omega FP6511 HOT TAP INSERTION PDLWHL SNSR
Condition: New
Usually ships Same Day or Next Day$2116.79
Sale Price
$1763.99
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Flow Sensor, Adjustable Length Insertion Paddlewheel, 5 Vdc to 24 Vdc, 0.3 FPS to 30 FPS, ± 1.5 %, Amplified Square Pulse, Brass, 200 psi, 2 " NPT Fitting, 3 " to 12 " Pipe, FP6500 Series, Each
Specifications
Manufacturer
Omega Engineering
(Instrument-Sensor) Supply Voltage
5- 24 VDC
(Instrument-Sensor) Span
0 To 200 Psi
Component
Paddlewheel Flow Meter
Features
Available in 316 Stainless Steel or Brass
Installs in a Wide Range of Pipe Sizes From 3' to 40'
Excellent Low-Flow Performance
Special Fittings Not Required
Accuracy± 1.5 %
ApprovalsRoHS, CE
Cable Length18 ft
Cable Length Note#22 AWG 3-conductor, 5.5 m (18') standard
610 m (2000') max
Cable Type3 Conductor Wire Shielded Cable
Electrical OutputSquare Wave, current sinking output
K-Factor11 Hz/fps
Mounting OrientationN/A
Operating Pressure, Max200 psi
Operating Pressure, Min0 psi
Operating Pressure Note200 psi at 24°C
Output DetailSquare wave, 11 Hz/fps
(approx.), current sinking output,
20 mA maximum, NPN (Hall Effect)
Pressure TypeGauge
Process Connection TypeNPT Male
Process Temperature, Max93 °C
Process Temperature Note93°C (200°F) at 0 psig
Supply Current1.5 mA
Supply Power Note5 to 24 Vdc, 1.5 mA
Supply Voltage5 to 24 Vdc
Velocity, Max30 ft/s
Velocity, Min0.3 ft/s
Wire Gauge22 AWG
DPF700
DPF70
DPF11
FC-21, 22
