High Precision

USB PC Interface

Thermocouple and RTD Models

Built-In Display for Selected Channel or Scanned Channels

Accuracy± 0.1 °C (± 0.18 °F)

Accuracy DetailThermocouples J, K, T, E, and N, better than ±0.1°C ±0.1% of range zero to span ±0.15% of range -100 to - 200°C (J, K, T, and E)

Additional Features 1Real Time Logging, AC Adapter Provided

Calibration NoteUser facility incorporated

the instrument auto-calibrates on every A/D cycle

Cold Junction CompensationAutomatic, accurate reference

Connection Note8 x thermocouple, mini connectors

Data InterfaceUSB

Display and IndicationsChannel number, measured temperature (°C or °F)

Display TypeSingle 5 Digit LCD

Display Type NoteLCD, backlight, Display Resolution: Thermocouple ranges 0.1°C, Pt100 range 0.01°C

Form factorBenchtop

Input Type NoteThermocouples: R, S, and B, better than ±0.1°C ±0.15% of range Pt100 Range: Better than ±0.05°C ±0.1% of range

Linearization Points±0.05°C

Logging Interval0

Material Construction OptionN/A

Measuring RangeType J: -200 to 750°C (-328 to 1382°F) Type K: -200 to 1200°C (-328 to 2192°F) Type T: -200 to 350°C (-328 to 662°F) Type E: -200 to 900°C (-328 to 1652°F) Type N: 0 to 1300°C (32 to 2372°F) Type R: 0 to 1760°C (32 to 3200°F) Type S: 0 to 1760°C (32 to 3200°F) Type B: 300 to 1800°C (572 to 3272°F)

Number of Inputs8

Operating Temperature, Max50 °C

Operating Temperature, Min0 °C

Sampling Rate0.5 Hz (2 seconds between updates)

Storage Temperature, Max70 °C

Storage Temperature, Min-20 °C

Supply Power Note6 Vdc (5.5 to 9.0V) via universal mains adaptor (supplied), 120 to 250V, 50/60 Hz

Supply Power TypeDC

Supply Voltage6 Vdc

Temperature Drift±0.01% of span per °C

Terminal block8 x Pt100

Thermal Effect Zero Shift±0.01% of span per °C

Thermocouple TypeN/A

User InterfaceFront panel key for channel number or auto-scan selection

PC software for all other functions
