Base Model Starting from $80

Fast Sampling Time 0.1 sec

Heater Disconnection Detection

All 1/4, 1/8, 1/16 DIN Models UL/cUL Certified

Altitude,Max2000 m

Control ModePID Control, Fuzzy Control, Self-tune, Manual tuning, On-off control

Display Type NoteLCD display. Process value (PV): Yellow color, Set point (SV): Green color, 3.5 Digit Dual Display Display Accuracy: 0 or 1 digit to the right of the decimal point (selectable)

Input TypeThermocouple, RTD, mA, Voltage

Measurement TypeCurrent, Temperature, Voltage

Measuring RangeType K: -200 ~ 1300°C, Type J: -100 ~ 1200°C, Type T: -200 ~ 400°C, Type E: 0 ~ 600°C, Type N: -200 ~ 1300°C, Type R: 0 ~ 1700°C, Type S: 0 ~ 1700°C , Type B: 100 ~ 1800°C, Type L: -200 ~ 850°C, Type U: -200 ~ 500°C, Type TXK: -200 ~ 800°C, RTD (JPt100): -20 ~ 400°C, RTD (Pt100): -200 ~ 850°C, Resistance (Ni120): -80 ~ 300°C, Resistance (Cu50): -50 ~ 150°C, Analog Voltage Input (0~5V): -999~9999, Analog Voltage Input (0~10V): -999~9999, Analog Voltage Input (0~20m A): -999~9999, Analog Voltage Input (4~20m A): -999~9999, Analog Voltage Input (0~50m V): -999~9999

Number of Inputs1

Operating Temperature, Max50 °C

Operating Temperature, Min0 °C

Output SignalNone

Ramp and SoakMultiple Ramp & Soak

Relative Humidity35% ~ 80% RH（non-condensing）

RTD Type100 Ω pt or Jpt sensor

3-wire Pt100

Sampling Rate10 Hz (10 updates/second)

Sampling Rate NoteAnalog input: 0.1 sec/scan

Thermocouple or Platinum RTD: 0.1 sec/per scan

Shock ResistanceMax. 300m/ s² , 3 times in each 3 axes, 6 directions

Storage Temperature, Max65 °C

Storage Temperature, Min-20 °C

Supply Power Note80 ~ 260Vac 50/60Hz

24Vac 50/60Hz ± 10%

24 Vdc ± 10%

Thermocouple TypeJ, K, T, E, N, R, S, B, L, U, TXK

Vibration Resistance10 to 55Hz, 10m/s² for 10min, each in X, Y and Z directions
