Code: 777002
Omega DP25B-TC-AR TEMPERATURE METER BIG DSPLY CE
Normally In Stock
Omega DP25B-TC-AR TEMPERATURE METER BIG DSPLY CE
Condition: New
Usually ships Same Day or Next Day$957.83
Sale Price
$798.19
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Temperature Panel Meter, Thermocouple I/P, 1/8 DIN, 3.5 Digit, 9-Segment Selectable Color LED Display, 115 Vac, Analog & 1 Relay Alarm O/P, DP25B Series, Each
Specifications
(Instrument-Sensor) Supply Voltage
115 VAC
Component
Temperature Panel Meter
Manufacturer
Omega Engineering
Features
Big Bright LED Display
Peak Recall
Dual Programmable Setpoints
Optional Analog Output
Accuracy± 0.5 °C
Accuracy Detail±0.50°C (0.9°F) after 30 min warm-up
Analog-to-Digital TechniqueDual slope
CMRR120 dB
Cutout Dimensions45 x 92 mm
Display NoteDisplay: 4-digit, 9-segment, 21 mm (0.83") red, amber or green LED (programmable)
Display Size21 mm (.82 in)
Display Type4 Digit LED
Form factor1/8 DIN
Height48 mm
Input Resistance100 MΩ
IsolationDielectric strength to 2500V transient per 3 mm spacing based on EN 61010 for 260 Vrms or Vdc
Length152 mm
Measurement TypeTemperature
NMRR60 dB
Number of Inputs1
Operating Temperature, Max50 °C
Operating Temperature, Min0 °C
PolarityAutomatic
Power Consumption8 W
Reading Rate3/sec
Relay NoteHysterisis: Programmable from 0 to 9999
Resolution15 bit
Samples,Max3 Hz
Step Response2 sec
Storage Temperature, Max85 °C
Storage Temperature, Min-40 °C
Temperature Coefficient±50 PPM/°C
Temperature Sensor TypeThermocouple
Thermocouple TypeJ, K, T, E, L (J DIN)
Weight36 g
Width96 mm
