Omega AU-AMT8-D2 DIN RAIL DIGITAL MULIT TIMER
Normally In Stock
Code: 775708
Omega AU-AMT8-D2 DIN RAIL DIGITAL MULIT TIMER
Condition: New
Usually ships Same Day or Next Day$163.76
Sale Price
$136.47
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Digital Timer, 8 Multi-Functions, DIN Rail Mount, 3 Digit, LCD Display, AC/DC Supply, 2x Relay Alarm O/P, AU-AMT Series, Each
Specifications
(Instrument-Sensor) IP Protection
IP30
Component
Timer
Manufacturer
Omega Engineering
(Instrument-Sensor) Supply Voltage
24 - 265 Vac/Vdc
Features
Multifunctional Timer (8 or 18 Functions)
Universal Voltage 24 to 265 Vac/Vdc
Wide Time Range: 0.1 Seconds to 999 Hours
3 Digit LCD Display for Preset Time and Run Time
Accuracy± 0.5 %
Contact Rating8A @ 240 Vac/24 Vdc (resistive)
Display Type3 Digit Display
Electrical Life10,000 switching cycles
Enclosure RatingsIP30
Form factorDIN Rail
Frequency50/60 Hz
Height89 mm
Length76 mm
Measurement TypeTime
Mechanical Life2,000,000 switching cycles
Number of Relays1
Operating Temperature, Max55 °C
Operating Temperature, Min-10 °C
Power Consumption10 VA
Reset200 ms
Samples,Max1 Hz
Screw Terminal Torque0.40 Nm
Storage Temperature, Max65 °C
Storage Temperature, Min-20 °C
Supply Power TypeAC/DC
Supply Voltage24 to 265 Vac/Vdc
Terminal ProtectionIP29
Timer Range0.1 second to 999 hours
Weight85 g
Width17.5 mm
Wire Gauge22 to 14 AWG
