Mersen A6Y35-1R Fuse A6Y 600VAC 500VDC 35A Type 1R Ferrule Amp-Trap®
Normally In Stock
Code: 765349
Mersen A6Y35-1R Fuse A6Y 600VAC 500VDC 35A Type 1R Ferrule Amp-Trap®
Condition: New
Usually Ships Same Day or Next Day.$240.08
Sale Price
$200.07
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Mersen Form 600 fuses are the original current-limiting fuses, predating all the standards. Their 500V DC rating (through 600A) is a useful feature for special fusing applications. Form 600 fuses provide a high degree of current limitation in AC and DC applications. Types 1 and 3 are dimensionally interchangeable with Class H and K fuses. Types 4 and 5 have unique rejection dimensions and are not interchangeable.
Specifications
Fuse Voltage Rating
600 Volts
Manufacturer
Mersen
Fuse Amperage Rating
35 Amp
Component
Fuse
Body/Insulating Material
GMG
Connection/Terminal Material
Tin-Plated Copper
Mounting
Clip
Connection/Terminal Type
Ferrule
Features
Mersen Form 600 fuses are the original current-limiting fuses, predating all the standards
Their 500V DC rating (through 600A) is a useful feature for special fusing applications
Form 600 fuses provide a high degree of current limitation in AC and DC applications
Types 1 and 3 are dimensionally interchangeable with Class H and K fuses
Types 4 and 5 have unique rejection dimensions and are not interchangeable.
