Phoenix Contact 2910380 Type 1 surge protection device VAL-US-277/80/4+0-FM
Normally In Stock
Code: 71815
VAL-US-277/80/4+0-FM Phoenix 2910380 Surge arrester 240/415 VAC Plug-in/screw connection via COMBICON,Screw connection,Fork-type cable lug Type 1 surge protection device Surge Protection
Condition: New
Usually ships Same Day or Next Day$776.39
Sale Price
$646.99
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2910380 A four-channel surge protective device is available that meets the requirements for a 277/480 V AC, 4-wire plus ground system, and includes a remote indicator contact to monitor its status.
Specifications
Fault Warning
Optical
Fault Warning
Remote Indicator Contact
Arrester Class according to IEC
II
Arrester Class according to IEC
T2
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Surge Protector Type
Surge Arrester
Maximum Continous Voltage
264 Volt
Max Discharge Capacity
40 A
Nominal Discharge Current
20 Ka
Surge Protector Line Voltage
240-415 Volt
Component
Surge Protection Device
Features
Multi-channel type 2 protective devices
UL open terminal listed SPD
Optical, mechanical status indication for the individual arresters
With floating remote indication contact
Mechanical coding of all slots
Disconnect device on each individual plug
Secure hold of plugs in the event of high lightning current loads and strong vibrations thanks to new latching
Multi-channel type 2 arresters
Downloads
Phoenix 2910380 CAD data International.dxfPhoenix 2910380 CAD data International.pdfPhoenix 2910380 CAD data International.stpPhoenix 2910380 Flyer English.pdfPhoenix 2910380 Manufacturers declaration International.pdfPhoenix 2910380 Package Slip International.pdfPhoenix 2910380 Surge Protection English.pdfPhoenix 2910380 Tender Text English.zip
