Phoenix Contact 2910384 Type 1 surge protection device VAL-US-480D/30/1+0-FM
Normally In Stock
Code: 71796
VAL-US-480D/30/1+0-FM Phoenix 2910384 Surge arrester 480 VAC Plug-in/screw connection via COMBICON,Screw connection,Fork-type cable lug Type 1 surge protection device Surge Protection
Condition: New
Usually ships Same Day or Next Day$150.38
Sale Price
$125.32
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2910384 A surge protective device that monitors one AC power channel and provides remote indication when it reaches 480V, specifically designed to operate on a Delta configuration for AC systems at this voltage level.
Specifications
Max Discharge Capacity
350 V AC
Manufacturer
Phoenix Contact
Surge Protector Line Voltage
480 Volt
Component
Surge Protection Device
Features
Multi-channel type 2 protective devices
Mechanical coding of all slots
Optical, mechanical status indication for the individual arresters
With floating remote indication contact
Downloads
Phoenix 2910384 CAD data International.dxfPhoenix 2910384 CAD data International.pdfPhoenix 2910384 CAD data International.stpPhoenix 2910384 Flyer English.pdfPhoenix 2910384 Manufacturers declaration International.pdfPhoenix 2910384 Package Slip International.pdfPhoenix 2910384 Surge Protection English.pdfPhoenix 2910384 Tender Text English.zip
