ACI 148212 Current Transformer, 100A, Solid Core, Measure Canada Approved, 0.77" Aperture, 333mV Output, 1ft Leads - ACUCT-S77-100:333
Normally In Stock
Code: 715171
ACI 148212 Current Transformer, 100A, Solid Core, Measure Canada Approved, 0.77" Aperture, 333mV Output, 1ft Leads, S77 Solid Core
Condition: New
Usually ships Same Day or Next Day$59.04
Sale Price
$49.20
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
ACI 148212 Current Transformer, 100A, Solid Core, Measure Canada Approved, 0.77" Aperture, 333mV Output, 1ft Leads, S77 Solid Core
Specifications
Component
Current Transformer
Manufacturer
ACI
(Instrument-Sensor) Type
Solid Core
Features
The Solid-Core S77 High Accuracy Current Transformers are designed to convert an AC operating current into a low voltage AC millivolt signal for use with microprocessor-based circuits
These compact and light-weight solid-core current transformers are designed for installation on branch circuits for meter installations that require exceptionally accurate signal transformation
The S77 current transformer has been approved by Measurement Canada to be used in metering applications for installations used for billing purposes
CTs come standard unterminated stripped and tinned lead wires for easy connection to any of the Single or 3 Phase ACI power meter
CT models listed here are compatible with the ACI KW350-P1-D-S-SC, KW320-P1-D-W-SC-XX, KW320-P1-D-W-SC-PC, KW1850-P1-D-W, and KW1850-P1-D-S Power Meters where typical power measurements are required
For best accuracy, CTs should be selected based upon the expected maximum and minimum currents for the targeted application
The acceptable Measurement Current Range is referenced in the ordering grid table
Please contact ACI for more information regarding Solid-Core S77 High Accuracy Current Transformers.
