Code: 658512
Schneider Electric HMIG5U22 - base unit, Harmony GTU, Open BOX Windows 10, Universal Panel, with HMI software installed
Normally In Stock
Schneider Electric HMIG5U22 - base unit, Harmony GTU, Open BOX Windows 10, Universal Panel, with HMI software installed
Condition: New
Usually ships Same Day or Next Day$2399.41
Sale Price
$1999.51
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider Electric HMIG5U22 - base unit, Harmony GTU, Open BOX Windows 10, Universal Panel, with HMI software installed
Specifications
Manufacturer
Schneider Electric
Features
This product is part of the Pro-face SP5000 range, an offer of High performance IoT-ready modular HMI panels from 7 inch to 19 inch (Width) screen
The open box features Intel X86 1.33GHz processor and 32GB CFast card data storage, suits for universal panel
It is designed with backup memory of NVRAM 512kB and internal memory of RAM 4GB
This open box supports Windows 10 IoT Enterprise 2019 LTSC 32bit operating system
It is equipped with 10BASE-T/100BASE-TX/1000BASE-T Ethernet port
Communication port protocols are Modbus, Modbus TCP/IP and Uni-Telway
Its dimensions are 188mm (width) x 45mm (depth) x 131mm (height) and weighs 0.9kg
This product is not installed with HMI software
This product is certified by ATEX, IECEx, Ex CCC, CE, CULus, IEC, CUL, DNV-GL, RCM and EAC
It meets CSA C22.2 No 142, ANSI/ISA 12-12-01, UL 508, Class I division 2 CSA C22.2 No 213 and IEC 61132-2 standards
As a flagship model, SP5000 series, \Smart Portal\, is available
SP5000 series offers unprecedented solutions for utilization of increasingly sophisticated information.
