Eaton FAZ-D30/2-NA Mini CB - 30 Amp, Two Pole, 277 VAC, D Curve
Normally In Stock
Code: 609526
Eaton FAZ-D30/2-NA - FAZ branch protector,UL 489 Industrial miniature circuit breaker - supplementary protector,High levels of inrush current are expected,30 A,10 kAIC, 14 kAIC,Two-pole,277/480 V,10-20X /n,50-60 Hz,Screw terminals,D Curve
Condition: New
Usually ships Same Day or Next Day$131.15
Sale Price
$109.29
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton FAZ-D30/2-NA - FAZ branch protector,UL 489 Industrial miniature circuit breaker - supplementary protector,High levels of inrush current are expected,30 A,10 kAIC, 14 kAIC,Two-pole,277/480 V,10-20X /n,50-60 Hz,Screw terminals,D Curve - Magnetic range for higher startup inrush levels that are usually seen in motors and transformers, and other high inductive systems.
Specifications
Breaker Amperage Rating
30 Amp
Breaker Number of Poles
Two Pole
Breaker Voltage Rating
277 VAC
Breaker UL Rating
UL 489
Component
Miniature Circuit Breaker
Manufacturer
Eaton
Breaker Trip Speed
D Curve
Features
Designed for highly inductive loads
Response time of instantaneous trip: 10–20X I n current rating
UL recognized and CSA Certified as supplementary protectors
For international and domestic use (conform to IEC 60947-2)
UL file number 17745
