Eaton FAZ-C4/1-NA-DC-SP Mini CB - 4 Amp, Single Pole, 125 VDC, C Curve
Normally In Stock
Code: 609325
Eaton FAZ-C4/1-NA-DC-SP - FAZ branch protector,UL 489 Industrial miniature circuit breaker-supplementary protector,Single package,Medium levels of inrush current are expected,4 A,10 kAIC,Single-pole,125 Vdc per pole,5-10X/n,Q38,50-60 Hz,Screw terminals,C Curve
Condition: New
Usually ships Same Day or Next Day$75.50
Sale Price
$62.92
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton FAZ-C4/1-NA-DC-SP - FAZ branch protector,UL 489 Industrial miniature circuit breaker-supplementary protector,Single package,Medium levels of inrush current are expected,4 A,10 kAIC,Single-pole,125 Vdc per pole,5-10X/n,Q38,50-60 Hz,Screw terminals,C Curve - Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices. Single packaging of single-pole curves B, C and D for select amperages only.
Specifications
Breaker Amperage Rating
4 Amp
Breaker Number of Poles
Single Pole
Breaker Voltage Rating
125 VDC
Breaker UL Rating
UL 489
Component
Miniature Circuit Breaker
Manufacturer
Eaton
Breaker Overcurrent Protection Rating
10 Ka
Breaker Trip Speed
C Curve
Features
Designed for inductive loads
Response time of instantaneous trip: 5–10X I n current rating
UL recognized and CSA Certified as supplementary protectors
For international and domestic use (conform to IEC 60947-2)
UL file number 177451
