Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 598102
Eaton CHFN115AFCS CH AFCI Circuit Breaker - 15 Amp, 120/240 VAC, Single Pole
Normally In Stock
Eaton CHFN115AFCS - CH AFCI circuit breaker, AFCI Combination circuit breaker, Trip Flag, Trip-to-OFF handle, 3/4" width|Clamshell pack, 15 A, 10 kAIC, Single-pole, 120/240 V, CH, Pigtail, Type CH Loadcenters, Plug-on
Condition: New
Usually ships Same Day or Next Day$586.50
Sale Price
$488.75
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Eaton CHFN115AFCS - CH AFCI circuit breaker, AFCI Combination circuit breaker, Trip Flag, Trip-to-OFF handle, 3/4" width|Clamshell pack, 15 A, 10 kAIC, Single-pole, 120/240 V, CH, Pigtail, Type CH Loadcenters, Plug-on - 3" x 1" x 3.5" (HxWxD)
Specifications
Breaker Amperage Rating
15 Amp
Breaker Number of Poles
Single Pole
Breaker Voltage Rating
120 VAC
Breaker Voltage Rating
240 VAC
Manufacturer
Eaton
Component
AFCI Circuit Breaker
Features
Eaton's residential CH circuit breakers provide premium overload protection. The Type CH circuit breakers trip to the OFF position, eliminating nuisance callbacks.
The CHF family also includes a trip flag to differentiate between a trip and the breaker being turned off. Handles are marked with ON-OFF indication and ampere rating of the breaker.
The thermal-magnetic trip curve avoids nuisance tripping on mild overloads while reacting almost instantaneously to severe short-circuit conditions. Multiple breakers have an internal common trip connection to operate all poles simultaneously.
