Absolute Process Instruments T121 Temperature Transmitter
Normally In Stock
Code: 582495
API T121 - Universal, isolated, DIN form B head-mount transmitter, Pt100 or Ni100, Pt500, Pt1000J, K, R, S, T, B, E, N, Pot., mVDC, VDC, Output: 4-20 mA or 20-4 mA
Condition: New
Usually ships Same Day or Next Day$193.19
Sale Price
$160.99
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
API T121 - Universal, isolated, DIN form B head-mount transmitter, Pt100 or Ni100, Pt500, Pt1000J, K, R, S, T, B, E, N, Pot., mVDC, VDC, Output: 4-20 mA or 20-4 mA
Specifications
Component
Temperature Transmitter
Manufacturer
Absolute Process Instruments
Conditioner Supply Voltage
7-30 VDC
Features
High precision temperature transmitters for head mounting, T120 and T121, are designed for universal use on machines, industrial plants, installations and in the process industry.
They convert the input signals and transmit them back into a normalised current signal via a 4-20 milliAmpere loop. The input signals can come from 2, 3, 4-wire RTD sensors such as Pt100 (EN 60751) and Ni100 (DIN 43760). T121 model also acquires Cu50, Cu100, Ni121 and Ni1000 thermoresistances and signals from thermocouples type J, K, R, S, T, B, E, N, L (EN 60584), voltage and resistance.
T120 and T121 are featured by reduced overall dimensions and connections via spring terminals. All available operating parameters can be configured using specific EASY SETUP / EASY LP software.Translated with www.DeepL.com/Translator (free version)
