Dwyer 16G-63-31 8g, 4g Temperature/Process Loop Controller
Normally In Stock
Code: 572376
Dwyer 16G-63-31 - 1/16 DIN temperature/controller, linear voltage/relay, RS485, 1 event input, temp retransmission
Condition: New
Usually ships Same Day or Next Day$231.24
Sale Price
$192.70
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer 16G-63-31 is a 8g, 4g Temperature/Process Loop Controller with a temperature range of 32 to 122°F (0 to 50°C) and an accuracy of ± 1.8°F plus ±0.3% of span (±1°C plus ±0.3% of span) at 77°F (25°C) after 20 minutes warm up. It operates on 100 to 240 VAC power or optional 24 VDC and has a storage temperature range of -42 to 150°F (-20 to 65°C). The controller features a 4 digit, 0.47" H (12mm) orange LCD for process value display and a 4 digit, 0.47" H (12mm) green LCD for set point value display. It accepts thermocouple, RTD, DC voltages or DC current inputs and has nonvolatile memory. The front panel is rated IP66 for protection and communication is enabled through RS-485 Modbus® ASCII/RTU. Control output options include relay (SPST, 5 A @ 250 VAC resistive), voltage pulse (12V max, 40 mA), current (4 to 20 mA), and linear voltage (0 to 10 V), with a relay rating of 3 A @ 250 VAC resistive.
Specifications
(Instrument-Sensor) Supply Voltage
24 VDC
(Instrument-Sensor) Measurement Accuracy
0.30%
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
(Instrument-Sensor) Supply Voltage
100-240 VAC
Component
Temperature Controller
Manufacturer
Dwyer Instruments
Features
On/off, PID, fuzzy logic, or manual output control
Constant, sloped, program (ramp/soak), or remote set point control
2 primary control outputs, 2 secondary/alarm relay outputs, and RS-485 standard on all models
Remote set point, input retransmission, or event input functions available with optional hardware
