Code: 571996
Dwyer 2-5000-125PA Minihelic® II Differential Pressure Gauge
Normally In Stock
Dwyer 2-5000-125PA - Differential pressure gauge, range 0-125 Pa.
Condition: New
Usually ships Same Day or Next Day$71.45
Sale Price
$59.54
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer 2-5000-125PA Minihelic® II Differential Pressure Gauge is designed for air and compatible gases. With an accuracy of ±5% at 70°F, it operates within a temperature range of 20 to 120°F. The gauge features a glass-filled nylon housing, a polycarbonate lens, and a diaphragm in a vertical position. It has a pressure limit of 30 psig and a barbed process connection for 3/16" ID tubing (1/8" male NPT optional).
Specifications
Component
Differential Pressure Gauge
(Instrument-Sensor) Application
Air And Compatible Gases
(Instrument-Sensor) Temperature Range
20 - 120°F/-6.67 - 48.9°C
(Instrument-Sensor) Measurement Accuracy
5.0%
Manufacturer
Dwyer Instruments
Features
Removable lens and rear-housing provides easy, cost-effective servicing
Accuracy and value provides an excellent solution for OEM and user applications
Durable housing materials make it well-suited for rough environments and total high pressure
