Dwyer ACT-MD04-110VAC Pneumatic/Electric Actuator
Normally In Stock
Code: 568357
Dwyer ACT-MD04-110VAC - Electric Modulating, 110 VAC, 1770 in-lb, black body, dome indicator, 1/2" NPT electrical connection
Condition: New
Usually ships Same Day or Next Day$2496.55
Sale Price
$2080.46
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer ACT-MD04-110VAC is a pneumatic and electric actuator with a temperature range of -40 to 140°F (-40 to 60°C). It has power requirements of 110 VAC, 220 VAC, 24 VAC, or 24 VDC and an enclosure rating of NEMA 7 for hazardous locations. The electrical connections are 1/2" female NPT and the material is powder coated aluminum. It has a cycle time, maximum supply pressure, and duty rating as specified in the instruction manual. The DA series is double-acting and the SR series is spring return with standard features including a position indicator and two limit switches. The supply pressure ranges from 40 to 115 psi for DA and 80 psi for SR. It has NAMUR standard accessory mounting and supports modulating input of 4 to 20 mA.
Specifications
(Instrument-Sensor) Supply Voltage
24 VDC
(Instrument-Sensor) NEMA Protection
NEMA 7
(Instrument-Sensor) Supply Voltage
24 VAC
(Instrument-Sensor) Supply Voltage
110 VAC
Component
Actuator
(Instrument-Sensor) Hazardous Location Class
Class I - Group C & D; Class II - Group E-G; Division I & II
(Instrument-Sensor) Temperature Range
-40 - 140°F/-40 - 60°C
Sub Component
Pneumatic/Electric Actuator
(Instrument-Sensor) Supply Voltage
220 VAC
Manufacturer
Dwyer Instruments
Features
ISO 5211 Mounting configuration for easy installation
Pneumatic actuators offer corrosion resistance anodized finish
NAMUR mounting configuration on pneumatic actuators
Two-position electric actuators include auxiliary limit switches
Modulating electric actuators offer an output for position monitoring
