Dwyer ACT-MD02-110VAC Pneumatic/Electric Actuator
Normally In Stock
Code: 568351
Dwyer ACT-MD02-110VAC - Electric Modulating, 110 VAC, 442 in-lb, black body, dome indicator, 1/2" NPT electrical connection
Condition: New
Usually ships Same Day or Next Day$1903.76
Sale Price
$1586.47
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer ACT-MD02-110VAC is a pneumatic and electric actuator designed for hazardous locations. It has a temperature range of -40 to 140°F (-40 to 60°C) and is available in 110 VAC, 220 VAC, 24 VAC, or 24 VDC power options. The enclosure is rated NEMA 7 and has 1/2" female NPT electrical connections. It features a position indicator, two limit switches, and NAMUR standard accessory mounting. The DA series is double-acting with a supply pressure range of 40 to 115 psi, while the SR series is spring return with a supply pressure of 80 psi. Modulating input is 4 to 20 mA.
Specifications
(Instrument-Sensor) Supply Voltage
24 VDC
(Instrument-Sensor) NEMA Protection
NEMA 7
(Instrument-Sensor) Supply Voltage
24 VAC
(Instrument-Sensor) Supply Voltage
110 VAC
Component
Actuator
(Instrument-Sensor) Hazardous Location Class
Class I - Group C & D; Class II - Group E-G; Division I & II
(Instrument-Sensor) Temperature Range
-40 - 140°F/-40 - 60°C
Sub Component
Pneumatic/Electric Actuator
(Instrument-Sensor) Supply Voltage
220 VAC
Manufacturer
Dwyer Instruments
Features
ISO 5211 Mounting configuration for easy installation
Pneumatic actuators offer corrosion resistance anodized finish
NAMUR mounting configuration on pneumatic actuators
Two-position electric actuators include auxiliary limit switches
Modulating electric actuators offer an output for position monitoring
