Dwyer ACT-MD01-110VAC Pneumatic/Electric Actuator
Normally In Stock
Code: 568348
Dwyer ACT-MD01-110VAC - Electric Modulating, 110 VAC, 265 in-lb, black body, dome indicator, 1/2" NPT electrical connection
Condition: New
Usually ships Same Day or Next Day$1918.27
Sale Price
$1598.56
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer ACT-MD01-110VAC is a versatile pneumatic and electric actuator designed for hazardous locations. With power options of 110 VAC, 220 VAC, 24 VAC, or 24 VDC, it offers a temperature range of -40 to 140°F. The NEMA 7 rated enclosure ensures safety, and it includes a position indicator, two limit switches, and NAMUR standard accessory mounting.
Specifications
(Instrument-Sensor) Supply Voltage
24 VDC
(Instrument-Sensor) NEMA Protection
NEMA 7
(Instrument-Sensor) Supply Voltage
24 VAC
(Instrument-Sensor) Supply Voltage
110 VAC
Component
Actuator
(Instrument-Sensor) Hazardous Location Class
Class I - Group C & D; Class II - Group E-G; Division I & II
(Instrument-Sensor) Temperature Range
-40 - 140°F/-40 - 60°C
Sub Component
Pneumatic/Electric Actuator
(Instrument-Sensor) Supply Voltage
220 VAC
Manufacturer
Dwyer Instruments
Features
ISO 5211 Mounting configuration for easy installation
Pneumatic actuators offer corrosion resistance anodized finish
NAMUR mounting configuration on pneumatic actuators
Two-position electric actuators include auxiliary limit switches
Modulating electric actuators offer an output for position monitoring
