Dwyer A2-7803 Subminiature Pressure Switch
Normally In Stock
Code: 568328
Dwyer A2-7803 - Subminiature pressure switch, brass, 50-150 psi (3.5-10.3 bar), flying leads, NO
Condition: New
Usually ships Same Day or Next Day$67.45
Sale Price
$56.21
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer A2-7803 is a subminiature pressure switch with a temperature range of -40 to 230°F (-40 to 110°C). It has an IP69 enclosure rating and offers two options for electrical connections - 1/4" spade terminals or flying leads. This switch is compatible with liquids and gases and has a pressure limit of 350 psi. It features a brass and polymide film wetted material, and a process connection of 1/8" or 1/4" male NPT. The switch type is SPST, 100 VA, 42 VDC, with a deadband of <10% of actuation point. Repeatability is ±3% of the highest set point at 70°F.
Specifications
(Instrument-Sensor) IP Protection
IP69
(Instrument-Sensor) Type
Miniature
(Instrument-Sensor) Application
Liquid
(Instrument-Sensor) Application
Gas
Component
Pressure Switch
(Instrument-Sensor) Temperature Range
-40 - 230°F/-40 - 110°C
Manufacturer
Dwyer Instruments
Features
High-proof pressure to meet application demands
Easy adjustment reduces installation and service times
