Dwyer A1F-O-SS-1-1 OEM Pressure Switch
Normally In Stock
Code: 568315
Dwyer A1F-O-SS-1-1 - Pressure switch, range 2-15 psig (0.14-1.03 bar), min. deadband 2 psig (0.14 bar), max. deadband 3 psig (0.21 bar).
Condition: New
Usually ships Same Day or Next Day$222.40
Sale Price
$185.33
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer A1F-O-SS-1-1 OEM Pressure Switch is a reliable and durable component suitable for various liquids and gases. It operates within a temperature range of -40 to 175°F (-40 to 80°C) and has a maximum pressure limit of 500 psig (34 bar). The switch features a SPDT snap switch and is equipped with screw terminals for easy electrical connections. It offers a set point adjustment with an indicating scale and is suitable for mounting within 20° of vertical. The pressure chamber is made of 316 SS while the diaphragm is made of Fluorocarbon. The switch has an electrical rating of 15 A @ 120/240/480 VAC and can handle 1/8 HP @ 125 VAC or 1/4 HP @ 250 VAC loads. The enclosure rating is optional and can meet NEMA 4X standards if the -PC enclosure is chosen.
Specifications
(Instrument-Sensor) NEMA Protection
NEMA 4X
(Instrument-Sensor) Application
Liquid
(Instrument-Sensor) Application
Gas
Component
Pressure Switch
(Instrument-Sensor) Temperature Range
-40 - 175°F/-40 - 80°C
Manufacturer
Dwyer Instruments
Features
15 A contact allows direct control reducing costs and reliability by having to introduce additional contacts and relays
Case style allows use for panel mounting application with optional weather-proof enclosure for use in outdoor environments
Field adjustable reduces installation time bring application on-line faster
Wetted material provides support for wider range of process media
