Code: 567758
Dwyer 2025 Magnehelic® Differential Pressure Gauge
Normally In Stock
Dwyer 2025 - Differential pressure gauge, range 0-25" w.c., minor divisions .50.
Condition: New
Usually ships Same Day or Next Day$92.77
Sale Price
$77.31
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer 2025 Magnehelic® Differential Pressure Gauge is a versatile and accurate gauge for measuring pressure differentials. It has a temperature range of 20 to 140°F (-6.67 to 60°C) with a low temperature option of -20°F (-28°C). With an accuracy of ±2% (±1% for -HA model) throughout the range at 70°F (21.1°C), it is suitable for a wide range of applications. The gauge has an enclosure rating of IP67 and is made of die-cast aluminum with a gray coated finish for corrosion resistance. It can be used with air and non-combustible gases (natural gas option available). The gauge has a 4" (101.6 mm) diameter dial face and comes with standard accessories including pressure taps and adapters. It has a pressure limit of -20 in Hg to 15 psig and is available with different pressure options. Overall, the Dwyer 2025 Magnehelic® Differential Pressure Gauge is a reliable and durable gauge for precise pressure measurement.
Specifications
(Instrument-Sensor) IP Protection
IP67
Component
Differential Pressure Gauge
(Instrument-Sensor) Application
Air And Non-Combustible Compatible Gases
(Instrument-Sensor) Temperature Range
20 - 140°F/-6.67 - 60°C
(Instrument-Sensor) Temperature Range
-20°F/-28°C
(Instrument-Sensor) Measurement Accuracy
2.0%
(Instrument-Sensor) Measurement Accuracy
3.0%
(Instrument-Sensor) Measurement Accuracy
4.0%
Manufacturer
Dwyer Instruments
Features
Easy to read gage through undistorted plastic face permits viewing from far away
Patented design provides quick response to pressure changes means no delay in assessing critical situations
Durable and rugged housing and high-quality components combine to provide longservice life and minimized down-time
High accuracy option is twice as accurate as the standard Magnehelic® gage
