Littelfuse KRPSA22B Time Delay Relay - 24-120 Volt, 24-120 Volt (DC), Double Throw, Single Pole
Normally In Stock
Code: 566270
Littelfuse KRPSA22B - Delay On Break Timer Series - 24-120 Volt, 24-120 Volt (DC) - Surface mount with 1 #10 (M5 x 0.8) screw - 10 A resistive @ 125 V ac; 5 A resistive @ 230 V ac and 28 V dc; 1/4 hp @ 125 V ac (MUST BUY IN PACKS OF 10)
Condition: New
Usually ships Same Day or Next Day$117.85
Sale Price
$98.21
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Littelfuse KRPSA22B is an encapsulated time delay relay with 10A resistive load rating at 125V AC and 5A resistive load rating at 230V AC and 28V DC. It features 0.25 in. male quick connect terminals, ±0.5% repeat accuracy, and ≤2% setpoint vs ambient temperature and operating voltage tolerance. With a life span of 1 x 10⁵ electrical and 1 x 10⁷ mechanical operations, it offers reliable performance.
Specifications
Relay Throws
Double Throw
Relay Poles
Single Pole
Manufacturer
Littelfuse
Component
Time Delay Relay
Relay Mounting
Surface Mount
Relay Timing Range
1 - 100 S
Sub Component
Delay On Break
Coil Voltage Rating
24-120 Volt
Coil Voltage Rating
24-120 Volt (DC)
