Littelfuse 201-200-SP Voltage Monitoring - 190-240 Volt, Double Throw, Single Pole
Normally In Stock
Code: 565715
Littelfuse 201-200-SP - 201-SP Series – Single-Phase Voltage/Phase Monitor Series - 190-240 Volt - DIN rail or surface mount (plug into OT08-PC socket) - Pilot Duty: 480 VA @ 240 VAC; General Purpose: 10 A @ 240 VAC
Condition: New
Usually ships Same Day or Next Day$188.52
Sale Price
$157.10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Littelfuse 201-200-SP is a versatile electrical panel mount relay with a load rating of 480VA @ 240V (pilot duty) or 10A @ 240V (general purpose). It features a torque termination type for easy installation and can accommodate 12-22 AWG solid or stranded wires. With an input AC line frequency of 50/60Hz, it is suitable for various applications. It has an undervoltage trip voltage of 90% and a trip delay range of 4s for under voltage faults. The maximum input power is 5W, and the restart delay range is 2s after a fault or complete power loss. The undervoltage reset voltage is 93%.
Specifications
Relay Throws
Double Throw
Relay Mounting
Din Rail
Relay Poles
Single Pole
Component
Voltage Monitoring Relay
Manufacturer
Littelfuse
Coil Voltage Rating
190-240 Volt
