Code: 562675
Littelfuse 0498030.H High Current Fuse - 30 Amp, 32 VDC
Normally In Stock
Littelfuse 0498030.H High Current Fuse - 30 Amp, 32 VDC
Condition: New
Usually ships same day or next day$9.23
Sale Price
$7.69
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Littelfuse 0498030.H - MIDI 32V Bolt Down Series Data SheetThis 30 A MIDI® fuse employs diffusion pill technology to offer time-delayed protection to high-current wiring harnesses. The bolt-down automotive fuse boasts a compact design, enabling greater circuit protection in less space. Features-Time-delayed-Tin-plated copper terminals-Benefits-Orange 30 A stamp aids identification-Clear top makes it easy to see when fuse blows-Available with one or two mounting holes
Specifications
Fuse Amperage Rating
30 Amp
Manufacturer
Littelfuse
Component
Fuse
Fuse Protection Type
Automotive
Fuse Type (UL)
High Current
Fuse Voltage Rating
32 VDC
Features
Available with ampere ratings of 30 A to 200 A
Interrupting rating of 2 kA at 32 V dc
Tin-plated copper terminals
Clear covers with UL 94 flammability ratings of HB on 30 A to 100 A fuses
Black housings with UL 94 flammability ratings of V-0
40 A to 100 A fuses comply with UL 248-1 as Special Purpose Fuses (UL file E71611) and Directive 2011/65/EU
M5 (4.5 Nm ±1 Nm) and M6 (6 Nm ±1 Nm) mounting holes
Certified lead-free and RoHS compliant
