Littelfuse 0298300.TXN High Current Fuse - 300 Amp, 32 VAC
Normally In Stock
Code: 561505
Littelfuse 0298300.TXN High Current Fuse - 300 Amp, 32 VAC
Condition: New
Usually ships same day or next day$25.25
Sale Price
$21.04
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Littelfuse 0298300.TXN - This 300 A MEGA® SLO-BLO® automotive fuse employs diffusion pill technology to provide time-delay circuit protection. Use it to protect against short circuits along heavy gauge wire harnesses, particularly those for batteries and alternators. Features-Grey 300 A stamp aids identification-Copper or silver-plated terminals-Refers to ISO 8820-5-Benefits-Available with two, one, or no mounting holes
Specifications
Manufacturer
Littelfuse
Fuse Amperage Rating
300 Amp
Component
Fuse
Fuse Voltage Rating
32 Volts
Fuse Response Time
Slo-Blo/Time Lag (T)/Time Delay
Fuse Protection Type
Automotive
Fuse Type (UL)
High Current
Features
Time-delayed
Available with ratings of 40 A to 500 A
Interrupting rating of 2 kA at 32 V dc
Brass (40 A and 60 A) and copper (80 A to 500 A) terminals, all available with silver plating
Operate at up to 125 ℃, with silver-plated terminals reaching 150 ℃ at contact point
UL 94 flammability rating of HB for housing
UL 94 flammability rating of V-2 for clear cover on fuses rated 40 A to 250 A
M6 (8–14 N) and M8 (12–18 N) mounting holes
Comply with ISO 8820-5
Certified lead-free and RoHS compliant
