Schneider SSLM1D101M7 Zelio Solid State SSL relay 90 VAC Single Pole Single Throw NO
Code: 50961
Schneider SSLM1D101M7 Zelio Solid State SSL relay 90 VAC-280 VAC coil voltage Single Pole Single Throw NO 1 Amp @ 28 VDC Single Phase 4 VDC-28 VDC Load voltage Din Rail mount (MUST BUY IN PACKS OF 12)
This product is now obsolete from the manufacturer
Below are replacement products designated by the manufacturer. See description and specs to assure they will work for your application.
Replacement Products
Description
Schneider SSLM1D101M7 Zelio Solid State SSL relay with is an innovative and reliable solid state relay. This relay uses 90 VAC-280 VAC coil voltage and has Single Pole Single Throw NO functionality. Has a load rated current of 1 Amp @ 28 VDC Single Phase and runs 4 VDC-28 VDC Load voltage and is Din Rail mounted.
Specifications
Relay Mounting
Din Rail
Relay Connection Type
Screw Connection
Relay Poles
Single Pole
Component
Relay Module-Solid State
Manufacturer
Schneider Electric
Line
Zelio
Relay Throws
Single Throw Normally Open
Coil Voltage Rating
90 Volt
Relay Load Amperage
1 Amp @ 28 Volt
Coil Voltage Max
280 Volt
Relay Load Voltage AC Phase
Single Phase
