Phoenix Contact 1745043 A printed circuit board terminal features a nominal current of 76 A and is rated for a voltage of 1000 V. It has a cross-sectional area of 16 mm2 and comes with 10 potentials connected across one row of 10 positions spaced at 10.16 mm apart. The connection method involves screwing onto a tension sleeve, using L-slotted screw heads. Wave soldering is used for mounting, while the conductor/PCB connection direction is 0 degrees, resulting in black coloration and a zigzag pin layout with solder pins of 5 mm length per potential, requiring two solder pins per potential. The terminal comes packaged in cardboard.
