Phoenix Contact 1987106 The printed circuit board terminal has a nominal current rating of 24A and is rated for 400V, with a cross-sectional area of 2.5mm². It features three potentials, arranged in a single row with three positions per row. The product falls within the MKDSN 2,5 range, with a pitch of 5.08mm. Connections are made via screw fasteners secured by tension sleeves, featuring L-slotted screw heads. Mounting is achieved through wave soldering, and the conductor/PCB connection direction is at 0 degrees. The terminal is colored green and has a linear pin layout, with individual solder pins spaced 3.5mm apart - one per potential - packaged in cardboard.
