Code: 42258
Phoenix Contact 3208200 Feed-through terminal block PT 1,5/S-QUATTRO RD
Normally In Stock
PT 1,5/S-QUATTRO RD Phoenix Contact 3208200 Feed Through Terminal Block - PT 1,5/S-QUATTRO RD Push-In Connection 1 Level 3.5 mm with 4 Connections. Not Grounded, Not Fused Red. 500 V, 17.5 A max rating.
Condition: New
Usually Ships Same day or Next Day$2.17
Sale Price
$1.81
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 3208200 The terminal block features a feed-through design with specifications including a nominal voltage of 500V and a nominal current capacity of 17.5A, accommodating four connections via push-in method, with cross-sectional ratings ranging from 0.14mm2 to 1.5mm2 across one level of mounting, utilizing the NS 35/7.5 or NS 35/15 mounting types and identified by its distinctive red color.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
500 Volt
Terminal Block Fused
Not Fused
Terminal Block Number of Levels
1
Terminal Block Number of Connections
4
Terminal Block Width
3.5 mm
Terminal Block Grounded
Not Grounded
Terminal Block Min Wire Size
26
Terminal Block Connection Method
Push-In Connection
Terminal Block Max Wire Size
16
Terminal Block Component Color
Red
Terminal Block Amperage
17.5 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Feed-Through Terminal Block
Sub Component
Multi-Conductor Terminal Block
Features
The compact design and front connection enable wiring in a confined space
The Push-in connection terminal blocks are characterized by the system features of the CLIPLINE complete system and by easy and tool-free wiring of conductors with ferrules or solid conductors
In addition to the testing option in the double function shaft, all terminal blocks provide an additional test pick-off
Downloads
Phoenix 3208200 CAD data International.dxfPhoenix 3208200 CAD data International.pdfPhoenix 3208200 CAD data International.stpPhoenix 3208200 Certification English.pdfPhoenix 3208200 Certification International.pdfPhoenix 3208200 Manufacturers declaration International-2.pdfPhoenix 3208200 Manufacturers declaration International-3.pdfPhoenix 3208200 Manufacturers declaration International-4.pdfPhoenix 3208200 Manufacturers declaration International.pdfPhoenix 3208200 Safety note English.pdfPhoenix 3208200 Tender Text English.zipPhoenix 3208200 User instructions for the Ex Area International.pdf
