Code: 41082
Phoenix Contact 2775207 Feed-through terminal block UDK 4-DUR
Normally In Stock
UDK 4-DUR Phoenix Contact 2775207 Feed Through Terminal Block - UDK 4-DUR Screw Connection 1 Level 6.2 mm with 4 Connections. Not Grounded, Not Fused Gray. 630 Volt, 32 Amp max rating.
Condition: New
Usually ships within 7-14 days. Call for ship time.$14.08
Sale Price
$11.73
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2775207 A feed-through terminal block suitable for installing individual components is available with a nominal voltage of 630 V and a nominal current capacity of 32 A. It has one level of connections, secured by screw connection, and comes in various cross-sectional sizes ranging from 0.2 mm2 to 6 mm2. The mounting options include NS 35/7.5, NS 35/15, and NS 32, all with a gray color and a maximum rated cross section of 4 mm2.
Specifications
Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
630 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
6.2 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
4
Terminal Block Component Color
Gray
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Min Wire Size
24
Terminal Block Max Wire Size
10
Terminal Block Amperage
32 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Feed-Through Terminal Block
Sub Component
Multi-Conductor Terminal Block
Features
The four-conductor connection enables user-friendly wiring
A voltage signal pick-off can be implemented in the measuring line using this terminal block, enabling the signal to be used as an analog signal for process computers
The constant circuits common in process automation transmit the measured values as a load-independent current of 0 ... 20 mA
