Code: 164615
Schneider XMLK200P2C23 0.00 - 1378.95 kPa Analog 4 - 20 mA Air,Fresh Water Electronic pressure sensors
Normally In Stock
Schneider XMLK200P2C23 0.00 - 1378.95 kPa Analog 4 - 20 mA Air,Fresh Water IP65 NEMA 4 24 VDC SELV Electronic pressure sensors
Condition: New
Ships in 6 weeks. CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $490 OF TELEMECANIQUE SENSORS FOR PRODUCT TO SHIP
*NON-CANCELLABLE, NON-RETURNABLE*
$134.22
Sale Price
$111.85
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider XMLK200P2C23 0.00 - 1378.95 kPa Analog 4 - 20 mA Air,Fresh Water IP65 NEMA 4 24 VDC SELV Stainless steel type AISI 303,Nitrile (NBR),Ceramic Transmitters for pumping applications Electronic pressure sensors
Specifications
Manufacturer
Telemecanique
(Instrument-Sensor) IP Protection
IP65
(Instrument-Sensor) Output Signal Type
Analog
(Instrument-Sensor) Standards
CE
(Instrument-Sensor) Medium
Air
(Instrument-Sensor) Medium
Fresh Water
(Instrument-Sensor) Supply Voltage
24 VDC SELV
(Instrument-Sensor) Connection Type
Male Connector 1/4" - 18 NPT
(Instrument-Sensor) Measurement Response Time
< 5 Ms
(Instrument-Sensor) NEMA Protection
NEMA 4
(Instrument-Sensor) Application
Transmitters For Pumping Applications
(Instrument-Sensor) Connection Type
Male Connector 4 Pins
Component
Electronic Pressure Sensor
(Instrument-Sensor) Output Signal Range
4-20 Mamp
(Instrument-Sensor) Temperature Range
0 - 80°C
(Instrument-Sensor) Span
0.00-1378.95 Kpa
Features
Type XMLK pressure transmitters are characterized by their ceramic pressuremeasuring cell.
The deformation caused by the pressure is transmitted to the resistors of a Wheatstone bridge silk-screened on the ceramic.
The change in resistance is then processed by the integrated electronics to provide an analog output signal.
