Phoenix Contact 1907759 The printed circuit board terminal has a nominal current rating of 22 A and is rated for 400 V with a cross-sectional area of 2.5 mm². It features ten potentials, arranged in two rows with five positions per row, fitting within the MKKDS 3 product range. The terminals have a pitch of 5.08 mm, utilizing screw connections with tension sleeves and L-slotted screw heads for wave soldering mounting at 0° angles, coloured green. The pin layout is linear and includes five-millimeter long solder pins per potential, packaged in cardboard.
